Manual for Synchronous Spindle Motor Drive Additional Manual Page 9

Additional Manual
9
Manual for
Synchronous Spindle Motor Drive
EDT. DATE DESIG. DESCRIPTION PAGE /29
A-63639E-103 /03
NO.
TITLE
NEWLY Y.Toyozawa
K.Takahashi
2003.06.13 01
02 2003.10.15 K.Takahashi
A
dded SSM etc. Y.Toyozawa
03 2004.06.09 K.Takahashi Revised Pole detect, etc. Y.Toyozawa
4. Input /Output signal
The below is the table of Input /Output signal to be need for the pole detection and SSM. The signal of bold
type character is added for the synchronous motor.
INPUT (PMC CNC)
15i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
G227 G070 G070 MRDY SFR SRV
G226 G071 G071 *ESP
G228 G073 G073
EPFSTR
MPOF
SYMBOL MEANINGS & REMARKS
MRDY Machine Ready completed
Please refer to chapter 7 (Pole position detection function) about the detail.
SFR
SRV
Forward Revolution command
Reverse Revolution command
These signal serve as both the rotation command and the trigger signal for pole
detection by inputting either SFR or SRV exclusive.
Please refer to chapter 7 (Pole position detection function) about the detail.
*ESP Emergency Stop
Please refer to chapter 7 (Pole position detection function) about the detail.
EPFSTR
The trigger signal to start the pole detection.
Please refer to chapter 7 (Pole position detection function) about the detail.
MPOF Motor power off signal
In case of driving with SSM (parameter SSMUSE=1), SPM will start up to SSM if
MPOF is entered.
Please refer to chapter 6 (Sub module for Synchronous Spindle Motor) about the
detail.
Don’t input this signal during the pole detection executes.
OUTPUT (PMC CNC)
15i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
F229 F045 F045 ALM
F230 F048 F048
EPFIX
SSMBRK
SYMBOL MEANINGS & REMARKS
ALM Alarm status
SPM module falls in alarm state
EPFIX
Pole position status
Please refer to chapter 7 (Pole position detection function) about the detail.
SSMBRK
SSM abnormal status
Please refer to chapter 6 (Sub module for Synchronous Spindle Motor) about the detail.
