Manual for Synchronous Spindle Motor Drive Additional Manual Page 28

Additional Manual
28
Manual for
Synchronous Spindle Motor Drive
EDT. DATE DESIG. DESCRIPTION PAGE /29
A-63639E-103 /03
NO.
TITLE
NEWLY Y.Toyozawa
K.Takahashi
2003.06.13 01
02 2003.10.15 K.Takahashi
A
dded SSM etc. Y.Toyozawa
03 2004.06.09 K.Takahashi Revised Pole detect, etc. Y.Toyozawa
8. Parameter table for each synchronous spindle motor
In this chapter, the follows describe the table of parameters for each synchronous spindle motor.
8.1 Procedure for spindle parameter initialization
Perform automatic spindle parameter initialization be following procedure below.
(1) Set model code “300” for parameter initialization.
In case of synchronous spindle motor, there is no model code. Therefore, set model code “300” for
automatic parameter initialization, then manually change the parameter data according to the table of
parameter for each synchronous spindle motor.
Parameter No.
15i 16i 30i
Settings
3133 4133 4133 Model code “300”
(2) Set the relevant parameter to the next table value to enable automatic spindle parameter initialization.
Parameter No.
15i 16i 30i
Settings
- 4019#7 4019#7 1
5607#0 - - 0
Note
This bit is reset to its original value after automatic parameter initialization.
(3) Turn the CNC off/on and the spindle parameters specified with the model code are automatically initialized.
(4) Manually change the parameter data according to the table of parameter for each synchronous spindle
motor.
(5) Set the detector-related parameters according to the configuration of the detector.
(6) Turn the CNC and SPM off/on again.
