Case of No.4084=”0”:
After the pole-detection is finished, the pole position
(*)
corresponds to the reference signal of the motor
sensor can be confirmed by using the spindle check board display or SERVO GUIDE arbitrary address
output. This confirmed data would be set to No.4084 as AMR offset value.
(*)
The standard of this pole-position is the detected pole-position by the pole-detection sequence
Case of No.4084<>”0”:
After the pole-detection is finished, SPM replaces the pole-position corresponds to the reference signal
position with No.4084 (AMR offset) when the reference signal position is first detected. This AMR offset
compensation will be decreased the dispersion of the pole-detection accuracy.
This parameter should be set the pole-position corresponds to the reference signal of the motor sensor. Set
the next data (value: 1 to 8192) to this parameter.
Confirmed data by spindle check board display or arbitrary address output of SERVO-GUIDE. The output
data will be changed from 0 to pole-position data correspond to the reference signal position when the
reference signal of motor sensor is first detected.
15i 16i 30I
3085 4085 4085 Excitation phase shift (9D53/C, 9D70/B or later)
This parameter shifts the excitation phase of the motor. By using this parameter, make a fine adjustment to
AMR offset. This parameter range is “-300” to “300” (-13.2 to 13.2 degrees: electrical angle). This parameter
must be set “0” if the software except the above is used.
This parameter should be tuned as the follows.
*) Observes torque-command and actual motor speed when the motor is rotated to CCW and CW direction.
*) This parameter should be tuned so that acceleration-time, deceleration-time, torque-command at CW
rotation is almost the same one at CCW rotation.
15i 16i 30I
#7 #6 #5 #4 #3 #2 #1 #0
3398 4398 4398 SELMET
SELMET: The selection of pole detection mode (9D53/C, 9D70/B or later)
This parameter must be set “0” if the software except the above is used.
=”0”: DC current mode (conventional mode)
=”1”: Auto mode (Minute moving mode + Stop state mode)
15i 16i 30I 5
th
4
th
3
rd
2
nd
1
st
(9D53/C, 9D70/B or later)
3449 4449 4449 5
th
, 4
th
, 3
rd
digit: Current value B for Stop state mode of pole detection (unit: %)
2
nd
, 1
st
digit: Current value C for Stop state mode of pole detection (unit: %)
When Stop state mode is executed at Auto mode of pole detection, this parameter is used. This parameter
must be set “0” if the software except the above is used.
5
th
, 4
th
, 3
rd
digit: Current value B for Stop state mode of Auto mode
Set the amount of current for pole direction detection in Stop state mode. If this parameter is “0”, 100% is
adopted as the current value. The aim of 100% setting is the case that 3A current flows by 200V(400V) input
voltage and 2.7mH(5.3mH) motor inductance.
2
nd
, 1
st
digit: Current value C for Stop state mode of Auto mode
Set the amount of current for magnetic polarity detection in the new mode. If this parameter is 0, 70% of the
maximum current parameter (No.4111: 16i) is adopted as the current value.
15i 16i 30I 5
th
4
th
3
rd
2
nd
1
st
(9D53/C, 9D70/B or later)
3450 4450 4450 5
th
, 4
th
, 3
rd
digit: Magnification to movable detection angle (unit: %)
2
nd
, 1
st
digit: Magnification to velocity feedback threshold (unit: %)
When Minute moving mode is executed at Auto mode of pole detection, this parameter is used. This parameter
must be set “0” if the software except the above is used.
5
th
, 4
th
, 3
rd
digit: Magnification to movable detection angle
During the minute moving mode, the motor moves and senses the position limited “movable detection
