Series 0i - MB Operators manual Page 396

Operators manual
PROGRAMMING
19. HIGH SPEED CUTTING
FUNCTIONS
B–63844EN/02
372
The AI advanced preview control/AI contour control function is provided
for high–speed, high–precision machining. This function enables
suppression of acceleration/deceleration delays and servo delays that
become larger with increases in the feedrate and reduction of machining
profile errors.
Look–ahead acceleration/deceleration before interpolation is enabled for
up to 20 blocks in AI advanced preview control or for up to 40 blocks in
AI contour control. This enables execution of smooth acceleration/
deceleration extending over multiple blocks and higher machining.
This function is enabled by setting the AI advanced preview control or AI
contour control mode.
G05.1 Q _ ;
Q1 : AI advanced preview control/AI contour control mode on
Q0 : AI advanced preview control/AI contour control mode off
NOTE
1 Always specify G05.1 in an independent block.
2 The AI advanced preview control/AI contour control mode
is also canceled by a reset.
3 When the AI contour control option is installed, the AI
contour control mode is enabled.
19.3
AI ADVANCED
PREVIEW CONTROL
FUNCTION/
AI CONTOUR
CONTROL FUNCTION
Overview
Explanation
D Format
