Series 0i - MB Operators manual Page 409

Operators manual

Page of 901

/ 901

PROGRAMMING

B–63844EN/02

19. HIGH SPEED CUTTING

FUNCTIONS

385

Axis control f : Can be specified. : Cannot be specified.

Name Function

Number of controlled axes 3 to 4

Number of simultaneously con-

trolled axes

Up to 4

Axis name The basic three axes are fixed to X, Y, and Z.

Other axes are any of U, V, W, A, B, and C.

Least input increment 0.001 mm, 0.001 deg, 0.0001 inch

One–tenth input increment 0.0001 mm, 0.0001 deg, 0.00001 inch

One–tenth input increment for each axis cannot be

used.

Simple synchronous control f If the AI advanced preview control/AI contour

control option is installed, however, switching

between synchronous and normal operation

cannot be performed during automatic opera-

tion (when the automatic operation signal (OP)

is set to 1) regardless of whether the AI ad-

vanced preview control/AI contour control

mode is set. In this case, switching causes a

PS213 alarm.

Angular axis control

Inch/metric conversion

(G20, G21)

f (*1)

Interlock f

Interlock for each axis f Movement along all axes stops.

To stop movement only along the interlock axis

in non–linear interpolation type positioning, set

bit 5 (AIL) of parameter No. 7054 to 1 and bit 4

(XIK) of parameter No. 1002 to 0.

Machine lock f When the machine lock signal for each axis

(MLK1 to MLK8) is turned on or off, accelera-

tion/deceleration is not applied to the axis for

which machine lock is performed.

Mirror image f

Stored pitch error compensation f

Position switch f Set bit 3 (PSF) of parameter No. 6901 to 1.

When this parameter is set to 1, the signal out-

put timing changes.

Abnormal load detection f

Manual handle interruption f Manual handle interruption is disabled during

switching to the AI advanced preview control/AI

contour control mode.

External pulse synchronization

Interpolation functions

f : Can be specified. : Cannot be specified.

Name Function

Positioning (G00) f

Single direction positioning (G60) f To perform single direction positioning in the AI

advanced preview control/AI contour control

mode, set bit 4 (ADP) of parameter No. 7055 to

Exact stop (G09) f

Exact stop mode (G61) f

Tapping mode (G63) f

Linear interpolation (G01) f

Circular interpolation (G02, G03) f (Circular interpolation for multiple quadrants is

enabled.)

Dwell (G04) f (Dwell with the time in seconds or speed speci-

fied) For dwell with the speed specified, anoth-

er option is required.

D Specifications
