MACRO COMPILER for 30i-A Operators manual Page 114

Operators manual
E.PARAMETERS APPENDIX B-66264EN/01
- 106 -
9033 M code for calling a user program as a subprogram
[Data type] Integer
[Valid data range] 1 to 99999999 (except 02, 30, 98, and 99)
Set an M code for calling a user program as a subprogram.
9038 Conversational macro main program number (for user screen 1)
9040 Conversational macro main program number (for user screen 2)
9041 Conversational macro main program number (for user screen 3)
[Data type] Integer
[Valid data range] 1 to 99999999
Set the main program number of a conversational macro.
NOTE
The program number specified in each parameter
is set in the corresponding conversational macro
execution control variable when the power is turned
on.
9039 Auxiliary macro main program number
[Data type] Integer
[Valid data range] 1 to 99999999
Set the main program number of an auxiliary macro.
NOTE
The program number specified in this parameter is
set in the auxiliary macro execution control variable
when the power is turned on.
9042 Code for subprogram call using a range specification M code (lower limit)
9043 Code for subprogram call using a range specification M code (upper limit)
[Data type] Integer
[Valid data range] 1 to 99999999
Set a range of codes for subprogram call using a range specification
M code.
