MACRO COMPILER for 30i-A Operators manual Page 97

Operators manual
B-66264EN/01 APPENDIX D.BOOT SYSTEM
- 89 -
Screen configuration (MEMORY CARD SYSTEM screen)
(1)
(2)
(3)
(4)
(5)
(1) Screen title.
(2) The size of the free space of the
Memory card is displayed.
(3) A list of files in the Memory card is
displayed.
(4) Returning to the MAIN MENU.
(5) Message
Operating procedure
(1) Select either the FROM SYSTEM or MEMORY CARD
SYSTEM screen.
(2) Select the file you want to delete.
(3) The following message is displayed for confirmation.
(4) Click the [YES] soft key to start reading. Click [NO] to cancel
reading.
(5) Upon normal termination, a message such as that shown below is
displayed. Click the [SELECT] soft key. In the event of an error,
see the list of error messages and corrective actions, given later.
Others (System files and user files on SYSTEM DATA DELETE screen)
The system files are protected from accidental deletion. User files,
however, are not protected. Protected system files can be overwritten
from the USER DATA LOADING / SYSTEM DATA LOADING
screen.
SYSTEM DATA DELETE
MEMORY CARD DIRECTORY (FREE[KB]: 5123)
1 G001A_B1.MEM 1048704 2003-01-01 12:00
2 G001A_B2.MEM 1048704 2003-01-01 12:00
3 END
*** MESSAGE ***
SELECT FILE AND HIT SELECT KEY.
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
*** MESSAGE ***
DELETE OK ? HIT YES OR NO.
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
*** MESSAGE ***
EXECUTING
ADDRESS xxxx:
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
*** MESSAGE ***
DELETE COMPLETE. HIT SELECT KEY.
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
