MACRO COMPILER for 30i-A Operators manual Page 118

Operators manual
E.PARAMETERS APPENDIX B-66264EN/01
- 110 -
9134 Start program number of macro call using an G code (specification of 3 sets)
(2nd set)
9135 Start G code of macro call using an G code (specification of 3 sets)
(3rd set)
9136 Count of macro call using an G code (specification of 3 sets)
(3rd set)
9137 Start program number of macro call using an G code (specification of 3 sets)
(3rd set)
[Data type] Integer
[Valid data range] Start G code
(Nos. 9045, 9129, 9132, and 9135) : -9999 to 9999 (except 0)
Count (Nos. 9046, 9130, 9133, and 9136) : 1 to 9999
Start program number (Nos. 9047, 9131, 9134, and 9137) :
1 to 99999999
If a negative value is set as a start G code number (Nos. 9045, 9129,
9132, and 9135), modal call results. Use bit 1 (MCT) of parameter No.
9163 for setting of move command call (G66)/call of each block
(G66.1).
