MACRO COMPILER for 30i-A Operators manual Page 115

Operators manual
B-66264EN/01 APPENDIX E.PARAMETERS
- 107 -
NOTE
1 If a value not within the specifiable range is set, or a
specified range is such that No. 9042 > No. 9043,
subprogram call using a range specification M code
is disabled.
2 An M code used for macro call/subprogram call is
not used as a calling code even when the M code is
within the setting range.
9111 Start M code of subprogram call using an M code (specification of 3 sets)
(1st set)
9112 Count of subprogram call using an M code (specification of 3 sets)
(1st set)
9113 Start program number of subprogram call using an M code (specification of
3 sets) (1st set)
9114 Start M code of subprogram call using an M code (specification of 3 sets)
(2nd set)
9115 Count of subprogram call using an M code (specification of 3 sets)
(2nd set)
9116 Start program number of subprogram call using an M code (specification of
3 sets) (2nd set)
9117 Start M code of subprogram call using an M code (specification of 3 sets)
(3rd set)
9118 Count of subprogram call using an M code (specification of 3 sets)
(3rd set)
9119 Start program number of subprogram call using an M code (specification of
3 sets) (3rd set)
9120 Start M code of macro call using an M code (specification of 3 sets) (1st set)
9121 Count of macro call using an M code (specification of 3 sets)
(1st set)
9122 Start program number of macro call using an M code (specification of 3 sets)
(1st set)
9123 Start M code of macro call using an M code (specification of 3 sets) (2nd set)
