MACRO COMPILER for 30i-A Operators manual Page 90

Operators manual
D.BOOT SYSTEM APPENDIX B-66264EN/01
- 82 -
D.2 SCREEN CONFIGURATION AND OPERATING
PROCEDURE
When the Boot System is first started, the MAIN MENU screen is
displayed. This screen is described below :
MAIN MENU screen
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(1) Screen title. The series and edition of
the BOOT SYSTEM are displayed at
the right end.
(2) Function for terminating the Boot
System and starting the CNC.
(3) Function for writing data to Flash ROM.
(4) Function for writing data to Flash ROM.
(5) Function for checking the edition of a
file in ROM.
(6) Function for deleting a file from Flash
ROM or Memory card.
(7) Function for making a backup copy of
the data stored on the Memory card.
(8) Function for backing up and restoring
the SRAM area
(9) Function for formatting a Memory card.
(10) Simple operating instructions and error
messages are displayed.
Operating procedure
Press the [UP] or [DOWN] soft key to select the desired function.
After positioning the cursor to the desired function, press the
[SELECT] soft key. Before executing a function, the system my
request confirmation from the operator by having him/her press the
[YES] or [NO] soft key.
Basic operation
SYSTEM MONITOR MAIN MENU 60W1 - 01
1.END
2.USER DATA LOADING
3.SYSTEM DATA LOADING
4.SYSTEM DATA CHECK
5.SYSTEM DATA DELETE
6.SYSTEM DATA SAVE
7.SRAM DATA BACKUP
8.MEMORY CARD FORMAT
*** MESSAGE ***
SELECT MENU AND HIT SELECT KEY.
[SELECT][ YES ][ NO ][ UP ][ DOWN ]
Position the cursor.
[ UP ]
[ DOWN ]
Select a function
[SELECT]
Check the selection
[ YES ]
[ NO ]
Execute the
function
Select END
Return to original
state
