B-66264EN/01 APPENDIX E.PARAMETERS
- 111 -
NOTE
1 In the following cases, this call is disabled:
<1> In a compile parameter, a value not within the
range is set.
<2> A defined G code range (start G code number
+ count) exceeds 99999999.
<3> A defined program number range (start
program number + count) exceeds 99999999.
2 An G code used for macro call, even when included
in the setting range, is not used as an instruction for
this subprogram call.
3 If duplicate G codes are set, the G codes are valid
according to the priority order below.
Three types of macro call using G codes are
available as indicated below. If the range of G
codes set in <1> duplicates the ranges of G codes
set in <2> and <3>, the G code priority order is,
from high to low, <1> to <2> to <3>.
<1>Individual specification :
Compile parameters (Nos. 9013 to 9022)
<2>Specification of 1 sets :
Compile parameters (Nos. 9045 to 9047)
<3>Specification of 3 sets :
Compile parameters (Nos. 9129 to 9131, 9132
to 9134, and 9135 to 9137)
9048 Graphic coordinate system shift amount (X-axis)
9049 Graphic coordinate system shift amount (Y-axis)
[Data type] Integer
[Unit of data] dot
[Valid data range] -320 to 319
Set a graphic coordinate system shift amount.
9054 Free space when the program write/delete function is executed
[Data type] Integer
[Unit of data] Page (500byte/page)
[Valid data range] 0 to
If the number of free pages in the program memory becomes the
number of pages set in this parameter or less, the functions for
program insertion (G320), block writing (G326, G329), and block
deletion (G327) are not executed. (Completion code #8529=203)
