MACRO COMPILER for 30i-A Operators manual Page 130

Operators manual
E.PARAMETERS APPENDIX B-66264EN/01
- 122 -
9051 Area number of P-CODE variables (#10000 and up)
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 1 to 10
Set the area number for the P-CODE variables (#10000 to #19999)
used by the macro executor of each path.
If the same area is selected for multiple paths, the P-CODE variables
can be shared as common variables among the multiple paths.
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
9052 Area number of extended P-CODE variables (#20000 and up)
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 1 to 10
Set the area number for the extended P-CODE variables (#20000 to
#19999) used by the macro executor of each path.
If the same area is selected for multiple paths, the extended P-CODE
variables can be shared as common variables among the multiple
paths.
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
9053 Number of P-CODE variables (#10000 and up)
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 0 to 10000
Set the number of P-CODE variables.
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
