E.PARAMETERS APPENDIX B-66264EN/01
- 116 -
E.2 EXECUTOR PARAMETERS
When the power is turned on, the executor parameters are not
initialized to the values set in P-CODE variables. So, these parameters
can be modified, for example, from the MDI panel.
#7 #6 #5 #4 #3 #2 #1 #0
9000 RSC STP
[Input type] Parameter input
[Data type] Bit path
# 2 STP When a conversational macro/auxiliary macro is executed using the
debug function:
0: The macro is executed in the continuous mode.
1: The macro is executed in the single block mode.
# 4 RSC Upon reset, the P-CODE macro common variables (#100 to #199) are:
0: Not cleared to <null>.
1: Cleared to <Null>.
NOTE
This parameter does not affect the custom macro
common variables #100 to #199, regardless of the
states of bits 0 (MV0) and 1 (MV1) of parameter
No. 9034.
The custom macro common variables #100 to #199
depend on bit 6 (CCV) of parameter No. 6001.
9002 Conversational macro/auxiliary macro program number subject to breaking
[Input type] Parameter input
[Data type] 2-word path
[Valid data range] 1 to 99999999
Set the program number of a conversational macro/auxiliary macro
subject to breaking by the debug function.
NOTE
If either this parameter or parameter No. 9003 is
set to a value other than 0 when the conversational
macro function is executed, the break function is
enabled, and the program number set in this
parameter and the sequence number set in
parameter No. 9003 are set as break conditions.
