LASER C1000/C2000/C4000/C6000-MODEL E Maintenance manual Page 125

Maintenance manual

Page of 384

/ 384

B-70315EN/02 4.MAINTENANCE

- 105 -

Quantity

No. Item Specifications

C1000-E C2000-E C4000-E C5000-E C6000-E

51 Water distributor A04B-0813-C420 0 1 0 0 0

52 Water distributor A04B-0815-C420 0 0 1 0 0

53 Water distributor A04B-0817-C421 0 0 0 1 0

54 Water distributor A A290-4562-V800 0 0 0 0 1

55 Water distributor B A290-4562-V801 0 0 0 0 1

56 Water distributor unit A A04B-0818-C420 0 0 0 0 1

57 Water distributor unit B A04B-0818-C421 0 0 0 0 1

58 Inverter A90L-0001-0500/8LF 1 1 1 0 0

59 Inverter A90L-0001-0464/CE 0 (1) (1) 0 0

60 Inverter A90L-0001-0500/16LF 0 0 0 1 1

61 Beam folding unit A04B-0810-C451 0 1 0 0 0

62 Beam folding unit A04B-0811-C451 0 0 1 0 0
