LASER C1000/C2000/C4000/C6000-MODEL E Maintenance manual Page 87

Maintenance manual
B-70315EN/02 3.INSTALLATION
- 67 -
4) CNL1 terminal
B8 PF2 A8 PF1
B7 OFI2 A7 OFI1
B6 A2 A6 A1
B5 EMS2 A5 EMS1
B4 RUN2 A4 RUN1
B3 SHL2 A3 SHL
B2 A2 SC
B1 IB2 A1 IB1
CNL1 pin arrangement (as viewed from the wiring surface)
a) PF1 and PF2
These terminals are for QF1 voltage tripping. Connect
+24 VDC and 0 V to PF1 and PF2, respectively.
b) SHL1 and SHL2
These terminals are for shutter interlocking. Strapping
these terminals enables the shutter to be opened and closed.
Contact current-carrying capacity : At least 1.2 A on 24
VDC
Wire: 1.25 mm2, 25 m or shorter
c) IB1 and IB2
These terminals are for semiconductor laser interlocking.
Strapping these terminals enables the semiconductor laser to
be turned on.
Contact current-carrying capacity: At least 10 mA on 30
VDC
d) A1 and A2
These terminals are for supplying power to the safety box in
the laser oscillator and switching on and off the laser
oscillator power supply.
Connect +24 VDC and 0 V to A1 and A2, respectively.
Current-carrying capacity: At least 250 mA
e) SC
This terminal is for outputting a shutter-closed signal. It
outputs the signal when the shutter is closed.
Connectable load capacity: 3 to 100 mA on 24 VDC
Note that the voltage applied to the load varies with the
current flowing through the load.
f) RUN1 and RUN2
Connect these terminals in series with the laser oscillator
start signal.
g) EMS1 and EMS2
Connect these terminals to emergency stop switch contact
signals.
