6. 2 Important Points
It is also possible to enter a certain combination of ’Pre Tools’
in the ’Pre Tool File’ during the program input, using the
’window function’.
Further more it’s possible to change the combination in the ’Pre
Tool File’ during program input, using the ’window function’.
Automatically selected pre tools could also be deleted directly
in the input mask and replaced by another pre tool. However
after this the following key must be pushed:
Soft-Key F.S.
AUTO
so that the new specification of the data is registered.
With milling it could be an advantage not to combine the
selected operational cutter, but instead to define it by entering
the ID-NR. directly into the input mask.
For this purpose you should enter for instance the ID-NR.
9020 (Chamfering tool)
then move the horizontal cursor to the right and give the
ID-NR’s of the other pre tools in the corresponding sequence.
The last tool should be at the left end.
Afterwards move the cursor downwards until the Soft-Key
F. S.
AUTO
appears, which then must be depressed too. Now the display
will look as follows:
9020 7020 7920
Chamfe Endmill Endmill
Under the tools name the corresponding follow-up process must
be given per Soft-Key.
9020 7020 7920
Chamfe Endmill Endmill
Chamfer Finish Rough
GEF # FL/ escap-04-012000
GFKE-0041A-EN Pre Tool File
