B-63344EN/02 SUPPLEMENT 3.USEFUL FUNCTIONS FOR MACHINING PROCESSES

- 197 -

(6) C-axis reverse tapping by milling, even spacing

M(Milling axis stop command P9876);

(M8/M9);

M(Milling reverse tapping pre-command P9089);

G97G98G40S_ T_ M(Forward milling axis rotation command P9877)

G80;

(Movement to the cutting start point)

G98(G84/G88)_ ;

(Second figure specification)

(nth figure specification)

G80M(Milling axis stop command P9876);

NOTE

When bit 4 (TTM) of parameter No. 9846 is set to 0

or when the bit is set to 0 and parameter No. 9089

is not set, reverse rotation may be specified as the

direction of rotation for tapping. In this case, P/S

alarm, "3008 A WRONG TOOL SELECTED," is

issued.

(7) C-axis forward tapping by milling, uneven spacing

M(Milling axis stop command P9876);

(M8/M9);

M(Milling forward tapping pre-command P9088); . . . (D)*

G97G98G40S_ T_ M(Forward milling axis rotation command P9877)

G80;

(Movement to the cutting start point)

G98(G84/G88)_ ;

G80M(Milling axis stop command P9876);

(Second figure specification)

M(Milling forward tapping pre-command P9088); . . . (D)*

M(Milling forward command P9877);

G98(G84/G88)_ ;

G80M(Milling axis stop command P9876);

(nth figure specification)

M(Milling forward tapping pre-command P9088); . . . (D)*

M(Milling forward command P9877);

G98(G84/G88)_ ;

G80M(Milling axis stop command P9876);

* Block (D) is output when bit 5 (MTM) of parameter No. 9846 is

set to 1 and a value is set for parameter No. 9088.
