C. APPENDIX C FANUC PANEL i
487
“BIOS Set–up” is a program to set up BIOS settings, and operating
environment for the Intelligent Terminal 3 is defined by these BIOS
setting.
It is unnecessary to run the set–up program normally because default
BIOS settings are set at shipping.
And use Intelligent Terminal 3 with this default environment as far as
possible because an inadvertent change to the operating environment may
cause a failure.
Use Intelligent Terminal 3 with default BIOS settings as far as possible.
Fanuc has not checked behavior of Intelligent Terminal in case that any
BIOS setting is changed from default settings. So if any setting is
changed, make sufficient confirmations.
BIOS Set–up is run by pressing F2 key on full keyboard from completing
memory check till OS loading as of 22.Aug.2000.
BIOS parameters are stored in an SRAM chip on the Intelligent Terminal
3. The SRAM is backed up by a battery.
A full keyboard is necessary at BIOS setup.
The keys used for set–up have the following functions.
– [°] [±] keys : Move the cursor to the next or previous item.
– [²] [³] keys : Move the cursor to the next or previous menu.
– [Enter] key : Select the sub–menu of the item in case of Main,
Advanced, and Power Savings Menu.
: Execute command in case of Exit Menu.
– [ESC] key : Exit.
– [–] [+] keys : Change values.
– [F1] key : Display helps.
– [F9] key : Setup defaults.
– [F10] key : Setup previous values.
C.3
BIOS SET–UP
C.3.1
What is BIOS SET–UP”
C.3.2
Keys Used for
Operation
Previous page
Next page
