PROGRAMMING

B–64134EN/01

13. FUNCTIONS TO SIMPLIFY

PROGRAMMING

153

CAUTION

D In each canned cycle,

R_ (distance between the initial level and point R) is always

handled as a radius.

Z_ or X_ (distance between point R and the bottom of the

hole) is, however, handled either as a diameter or radius,

depending on the specification.

D For the B or C G–code system, G90 or G91 can be used to

select an incremental or absolute command for hole

position data (X, C or Z, C), the distance from point R to the

bottom of the hole (Z or X), and the distance from the initial

level to the point R level (R).
