OPEN CNC (DNC Operation Management Package) Operators manual Page 109

Operators manual
B-63214EN/01 APPENDIX 2 SWITCHING THE MESSAGE LANGUAGE
- 93 -
To place the message files in the C:\Program Files\DNC
Operation Management Package\Message folder included in
DNC Operation Management Package folder C:\Program
Files\DNC Operation Management Package, specify MsgDir =
MESSAGE.
• Edit the [Files] section.
In the [Files] section, specify the files to be added, in the
following format:
Filex=filename
Each file specification line must begin with the keyword File. As
the argument x, specify a number. From the beginning of this
section, specify the numbers in ascending order, starting from 1.
Numbers cannot be skipped.
(Example) [Files]
File1=msg_bop.msg
File2=msg_menu.msg
File3=param16m.ini
The file name extension indicates the destination folder to which
the file is added.
Extension Destination folder
MSG
Message file folder specified in the [Setup] section
INI
INI file folder specified in the [Setup] section
DLL
Windows system folder
4. Copy ADDLANG.EXE, SETUP.LST, and other files to be added
into the same folder on the same disk.
When ADDLANG.EXE is executed, the files of the desired language are
installed.
ll Referencing a message file when customizing the screen
A message ID in a message file can be input using the dialog box of the
screen customize function. Input the message ID in the following format,
in the text box displayed for character string specification.
#[decimal] (Example: #1234)
