OPEN CNC (DNC Operation Management Package) Operators manual Page 15

Operators manual
B-63214EN/01 PREFACE
5
P-
Notation Conventions
The following explains the notation conventions used in this manual:
l Menu, command, and screen notations
Example Explanation
[File] menu Menu names are enclosed in brackets [ ].
[Setting...] Command names are enclosed in brackets [ ].
[Program Edit] screen Screen names (displayed on the title bars) are
enclosed in brackets [ ].
<OK> button Command buttons on the display are enclosed
in angle brackets < >.
l Key notations and operation
Example Explanation
[Enter] key Key names are enclosed in brackets [ ].
[Ctrl]+[Tab] keys When keys are to be pressed and held down
sequentially, the keys are indicated by
connecting them with +, as shown on the left.
Direction keys The [→], [←], [↑], and [↓] keys are
collectively called the direction keys.
l Mouse operations
Example Explanation
Click Press a mouse button, then release it
immediately.
Double-click Click a mouse button twice in quick
succession.
Drag Move the mouse while holding down a mouse
button, then release the button at a desired
location.
l Folders
This manual refers to directories and folders collectively as folders.
