OPEN CNC (DNC Operation Management Package) Operators manual Page 114

Operators manual
APPENDIX 3 MESSAGE FILE GENERATOR B-63214EN/01
- 98 -
* Message text file (The extension is always .txt.)
In this text file, message IDs and messages (in different languages) are
specified.
The data in this file is of the following format:
ID: MSG_ORDER <1>
eng: "Order"
jpn: " "
ger: "Reihenfolge" <2>
fre: "Ordre"
spa: "Orden"
ita: "Ordine"
ID: MSG_SAMPLE
eng: "111" , "222" "333\""
,"SECOND LINE " <3>
"THIRD LINE\"" , "END"
jpn: ...
...
<1> Message ID
Unique name assigned to each message.
The message ID must be specified using up to 16 characters.
<2> Language ID and messages in different languages
The language IDs specified in the message generator parameter file
and the messages written in the corresponding languages are specified.
Note the following restrictions:
• A character string following an exclamation mark (!), except for any
within a character string, is assumed to be a comment.
• An intervening blank or tab, except for any within a character string, is
ignored.
• A single character string must be enclosed by a pair of double
quotation marks.
• A single character string enclosed by a pair of double quotation marks
can be coded over multiple lines. Two or more character strings can
be coded on a single line.
For example, the message in <3> above, is displayed as follows:
111222333"SECOND LINE THIRD LINE" END
• The length of a single message is not limited. Each line can be up to
512 characters long.
