5. MONITORING THE PROGRESS OF DNC OPERATION B-63214EN/01
- 44 -
5.1 Monitoring the Progress of DNC Operation
This section describes the [DNC Operation Monitor] screen, which is used to
monitor the progress of DNC operation.
Once scheduled operation or subprogram call operation has started, the
[DNC Operation Monitor] screen can be used to monitor the progress of
DNC operation.
Procedure
l When Basic Operation Package 1 is not used
1. If the soft key is not currently displayed, press the
function selection key .
2. Press the soft key.
The [DNC Operation Monitor] screen appears.
l When DNC Operation Management Package is integrated with Basic
Operation Package 1
1. If the soft key is not currently displayed, press the
function selection key .
2. Press the soft key.
3. If the [DNC Operation Monitor] screen is not currently displayed,
press the chapter selection key . If the soft key does
not appear, press .
4. Press the soft key.
The [DNC Operation Monitor] screen appears.
