6. BALANCE CUT FAPT FUNCTION
(2–PATH LATHE ONLY)
PROGRAMMING AND
OPERATION BY Symbolic FAPT
197
Suppose the following process is defined.
NO. KIND OF MACHINING HEAD NO.
1 ROUGH. OF CUT. 1, 2 (BALANCE CUT TYPE B)
2 FIN. OF CUT. 1, 2 (BALANCE CUT TYPE A)
3 GROOVING 1
4 THREADING 2
At this time, the following data appears on the process editing screen.
NO. (HEAD 1) (HEAD 2) SPINDLE SPEED
1 ROUGH. OF CUT. BALANCE CUT G97 V120 M03 (1)
2 FIN. OF CUT. BALANCE CUT G96 V115 M03 (1)
3 GROOVING G96 V90 M03 (1)
4 THREADING G96 V130 M03 (2)
The soft keys for moving up and down the process (“HEAD 1 UP”, etc.)
are not valid in the balance cutting process.
6.4
PROCESS EDITING
SCREEN
Previous page
Next page
