Symbol CAPi T Operators manual Page 852

Operators manual
APPENDIX
B–63304EN/02
A. SETTING DATA,
SYSTEM PARAMETER, MTF
832
Parameter
No.
RemarksDescription
Initial
value
Format
0410 0, 1
designation (8 bits)
00000000 Single step of Y–axis center drilling process
Bit 0 Process start
Bit 1 Just before approach
Bit 2 Just before escape
0 : Not stopped
1 : StoppedBit
7
0
6
0
5
0
4
0
3
0
2 1 0Bit
0411 0, 1
designation (8 bits)
00000000 Single step of Y–axis drilling process
(refer to the parameter No.410)
0412 0, 1
designation (8 bits)
00000000 Single step of Y–axis tapping process
(refer to the parameter No.410)
0413 0, 1
designation (8 bits)
00000000 Single step of Y–axis pattern machining process
(refer to the parameter No.410)
0414 0, 1
designation (8 bits)
00000000 Single step of Y–axis contouring process
(refer to the parameter No.410)
0415 to
0419
0, 1
designation (8 bits)
00000000 Can’t use. (Don’t change the data.)
0420 Real number
2. mm specification
Clearance amount of Y–axis center drilling
0.08 inch specification
C1
Unit: mm or inches
0421 Real number Undefined Can’t use. (Don’t change the data.)
0422 Real number
2. mm specification
Clearance amount of Y–axis drilling
0.08 inch specification
(machining method 1) C1
Unit: mm or inches
0423 Real number
2. mm specification
Clearance amount of Y–axis drilling
0.08 inch specification
(machining method 1) C2
Unit: mm or inches
0424 Real number Undefined Can’t use. (Don’t change the data.)
0425 Real number
2. mm specification
Clearance amount of Y–axis drilling
0.08 inch specification
(machining method 2) C1
Unit: mm or inches
0426 Real number
2. mm specification
Clearance amount of Y–axis drilling
0.08 inch specification
(machining method 2) C2
Unit: mm or inches
0427 Real number
2. mm specification
Cutting depth of Y–axis drilling (machining
0.08 inch specification
method 2) D1
Unit: mm or inches
0428 Real number
2. mm specification
Return relief amount of C–axis drilling
0.08 inch specification
(machining method 2) U
Unit: mm or inches
0429 Real number Undefined Can’t use. (Don’t change the data.)
