Symbol CAPi T Operators manual Page 539

Operators manual
B–63304EN/02
8. C–AXIS FAPT FUNCTION BC–AXIS FAPT FUNCTION
519
(3)Cutting condition parameters
No. Format Initial value Description Remarks
0390 Real
Number
2.(mm)
0.08(inch)
Clearance value for C–AXIS REAMING (C1)
Unit: mm or inch
Note 1
0391 Real
Number
2.(mm)
0.08(inch)
Clearance value for C–AXIS REAMING (C2)
Unit: mm or inch
Note 1
0392 Real
Number
5. Retracing feed rate override for C–AXIS REAMING (1.0–10.0)
0393 Real
Number
2.(mm)
0.08(inch)
Clearance value for C–AXIS BORING (C1)
Unit: mm or inch
Note 1
0394 Real
Number
2.(mm)
0.08(inch)
Clearance value for C–AXIS BORING (C2)
Unit: mm or inch
Note 1
0395 Real
Number
0. Dwell time for C–AXIS BORING
0396 Real
Number
2. Retracing feed rate override foe C–AXIS BORING (1.0–10.0)
NOTE
When saved into the sub–memory, these data are stored in
appropriate place which corresponds to the current setting
of the increment system.
(4)System Parameters concerning Color Display
No. Format Initial value Description Remarks
0591 Integer 2 Color of the Machining path of C–AXIS REAMING Green
0592 Integer 2 Color of the Machining path of C–AXIS BORING Green
(1)Machine Tool File
No. Format Initial value Description
1304 0,1
designation
(8 bits)
00000011 Used fixed cycle or not. (for C/Y–AXIS only)
0 : Do not use
1: Use fixed cycle for corresponding process.
7 6 5 4 3 2 1 0Bit
Center Drilling
Drilling
C–AXIS Boring
1313 Integer –1 M–code for forward tool rotation
1314 Integer –1 M–code for reverse tool rotation
8.3.2
MTF Parameters
