6. SUPPLEMENTANIMATED SIMULATION FUNCTION II

707

MTF

Parameter No. Description Remarks

2220 Start of C–axis center drilling Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2221 Start of C–axis drilling Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2222 Start of C–axis tapping Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2223 Start of C–axis grooving Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2224 Start of C–axis notching Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2225 Start of C–axis cylindrical grooving Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2230 End of C–axis center drilling Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2231 End of C–axis drilling Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2232 End of C–axis tapping Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2233 End of C–axis grooving Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2234 End of C–axis notching Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2235 End of C–axis cylindrical grooving Only for 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T

2070 Start of Y–axis process

2071 Start of Y–axis center drilling

2072 Start of Y–axis drilling

2073 Start of Y–axis tapping

2074 Start of Y–axis grooving/pocketing

2075 Start of Y–axis optional figure

(2)Drawing of a tool tip figure using animated simulation is performed

within a rectangle having the following size:

Vertical size: approximately 45 mm

Horizontal size:approximately 36 mm

(3)If two or more of the following conditions overlap, animated

simulation may not follow the operation of the NC program.

D Simultaneous machining has been performed using balance cut.

D The holder displayed on the screen is too large.

D An extremely high feedrate is set for NC program operation.

In this case, the following symptoms can be observed.

D The tool path is not displayed correctly.

D Part of a figure can not be cut.

In such cases, correct the setting as follows:

D Make the size of the holder figure smaller.

D Scale down the drawing.

D Make the feedrate in the NC program operation slower.
