Symbol CAPi T Operators manual Page 859

Operators manual

Page of 990

/ 990

B–63304EN/02

A. SETTING DATA,

SYSTEM PARAMETER, MTF

APPENDIX

839

Parameter

No.

RemarksDescription

Initial

value

Format

0729 Integer 2 Display language switching parameter

1: Japanese 2: English 3: German

4: French 5: Swedish 6: Finnish

7: Norwegian 8: Danish 9: Chinese

10: Dutch 11: Italian 12: Spanish

(Otherwise English display)

The

optional

ROM is

required for

Swedish

and the

languages

beyond it.

0730 Integer 100 Initial value of waiting M code

15–TTF

0731 Integer 200 Initial value of waiting M code which is inserted automatically

in ACA

only

0732 Real number Undefined Value of the M code for inverting a workpiece

Value of the M code for starting Y–axis machining

0733 Real number Undefined Value of the M code for ending Y–axis machining Only for the

5710 and

5800 and

5E00

0734 Real number Undefined Value of the M code for ending Y–axis machining Only for the

5710 and

5800 and

5E00

0735 Real number 500 Initial value of the waiting M code for each machining path

when using balance cut B.

Only for TT

0736 Integer Undefined M code number (for the second spindle) for starting animated

simulation for lathe turning surfaces

Not to be specified if only animated simulation for lathe turning

surfaces is performed.

0737 Integer Undefined M code number (for the second spindle) for starting animated

simulation for C–axis end facing

0738 Integer Undefined M code number (for the second spindle) for starting animated

simulation for cylindrical surfaces

0739 Integer Undefined Password for protecting a file

0740 Integer Undefined M code number for the start of turning

Setting of this parameter can be omitted when only turning is

performed. However, it cannot be omitted when turning is

performed after C– or Y–axis machining.

Only for the

5900 and

5F00

systems

0741 Integer Undefined M code number for the start of C–axis machining (switching to

the C–axis animated simulation screen)

Only for the

5900 and

5F00

systems

0742 Integer Undefined M code number for the start of cylindrical grooving (switching

to the cylindrical groove animated simulation screen)

Only for the

5900 and

5F00

systems
