C–AXIS FAPT FUNCTION

B–63304EN/02

8. C–AXIS FAPT FUNCTION B

506

Following parameters, related to the setting of the tool, are common

for both C–AXIS REAMING tool and C–AXIS BORING tool.

SETTING DIRECTION CP= () 0:SIDE 1:END) . . . .

SETTING OPTION XS=. . . . . . . .

ZS=

ROTATE DIRECTION TR= (0:NOMAL 1:REVERS). . . . .

HOLDER NO. HL=. . . . . . . . . . . .

MACHINING START POSITION:

DX0=

Z0=

Tool data definition method for other type of tools is the same as that

of C–AXIS FAPT FUNCTION.

(3)Cutting Area Definition

Definition method of the cutting area is the same as that of C–AXIS

FAPT FUNCTION.

When C–AXIS REAMING or C–AXIS BORING is selected as the

machining type, the cursor blinks on one of the figures listed bellow

which can be machined by these machining methods.Move the cursor

by pressing “CURSOR FORWARD” or” CURSOR BACK” soft–key

or by entering “0” (zero) and select the desired figure to be machined.

C–AXIS REAMING and C–AXIS BORING can be defined for the

following figures.

End face holes defined as C–AXIS figure.

Side face holes defined as C–AXIS figure.

(4)Cutting Condition

Definition method of cutting conditions for machining processes other

than C–AXIS REAMING and C–AXIS BORING is the same as that

of C–AXIS FAPT FUNCTION.

Cutting condition parameters for C–AXIS REAMING and C–ACIS

BORING are explained here.

(a) C–AXIS REAMING

Enter the following cutting conditions.

CLEARANCE C1= Clearance 1 (mm or inch) (The value. . . . . . . . . .

in the system parameter No.390 is

set as initial value.)

C2= Clearance 2 (mm or inch) (The value

in the system parameter No.391 is

set as initial value.)

RPM N= Tool Rotational Speed (rpm). . . . . . . . . . . . . . . . . .

FEEDRATE FT= Feed amount per revolution of the. . . . . . . . . . . .

tool (mm/rev or inch/rev)
