APPENDIX

B–63304EN/02

A. SETTING DATA,

SYSTEM PARAMETER, MTF

842

NOTE

The undefined character parameter is indicated with the “J” code. To return to undefined data

after setting data at the undefined parameter, input two or more SP codes. In this case, instead

of the “J” code, a space is displayed on the CRT. To change the undefined parameter to

undefined data, input

and .

DEL

INPUT

System Parameter Table Concerning Color Display

Parameter

No.

Coloring

data type

Standard

value

Details

0500 Graphic 4 Fixed picture for drawing format setting.

0501 Graphic 4 Fixed picture for blank figure and base line setting.

0502 Graphic 3 Not used.

0550 Graphic 0 Axis.

0551 Graphic 2 Lines that indicate blank figure.

0552 Graphic 1 Lines that indicate machining figure.

0553 Graphic 7 Threading area when machining is defined by menu No.4.

0554 Graphic 4 Center drilling tool path.

0555 Graphic 4 Drilling, reaming or tapping path.

0556 Graphic 2 Outside–diameter rough machining tool path.

0557 Graphic 2 Inside–diameter rough machining tool path.

0558 Graphic 2 Outside–diameter semi–finish machining tool path.

0559 Graphic 2 Inside–diameter semi–finish machining tool path.

0560 Graphic 6 Outside–diameter finish machining tool path.

0561 Graphic 6 Inside–diameter finish machining tool path.

0562 Graphic 5 Grooving and necking tool path.

0563 Graphic 3 Threading tool path.

0570 Graphic 2 Machining path for Y–axis machining (center drilling)

0571 Graphic 2 Machining path for Y–axis machining (drilling)

0572 Graphic 2 Machining path for Y–axis machining (tapping)

0573 Graphic 2 Machining path for Y–axis machining (patten machining)

0574 Graphic 2 Machining path for Y–axis machining (contouring)

0575 to

0578

– Undefined Not used.

0579 Graphic 6 Y–axis machining parts figure

0580 Graphic 2 Machining path for C–axis machining (center drilling)

0581 Graphic 2 Machining path for C–axis machining (drill)
