15. ACCURACY COMPENSATION
FUNCTION
B–63122EN/01
NC FUNCTION
106
Parameters and pitch errors data can be set by tape commands. therefore,
following uses can be done example.
Parameter setting such as pitch errors compensation data, etc. when
the attachment is replaced.
Parameters such as max. cutting speed and cutting feed time constant
can be changed according to the machining conditions.
G10 L50 ;
N_ P_ ;
N_ P_ R_ ;
:
N_ R_ ;
G11 ;
G10 L50 : Parameter input mode
G11 : Parameter input mode cancel
N_ : Parameter No. (or pitch error data No.+10000)
P_ : Axis No. (in the case of axis type parameter)
R_ : Parameter setting value (or pitch error data)
NOTE
Some parameters cannot be set.
C–axis backlash compensation can be effected for die–indexable tools for
individual indexes. Changing the backlash compensation value by index
enables high–precision machining. The amount of compensation and the
tool number for the die–indexable tool are specified by parameters. (Up
to 20 tools with tool numbers of 1 to 9999)
15.5
PROGRAMMABLE
PARAMETER ENTRY
(G10, G11)
Format
15.6
C–AXIS BACKLASH
COMPENSATION
FOR INDIVIDUAL
INDEXES (OPTION)
