SERIES 16/18/160/180 i PA Descriptions Page 22

Descriptions
B–63122EN/01
2. LIST OF SPECIFICATIONS
GENERAL
12
Others
Item Specifications
16i–PA
160i–PA
18i–PA
180i–PA
Status output signal NC ready, servo ready, automatic operation,re-
set,alarm, etc.
Display incorporated in the control unit
7.2″ monochrome LCD *1
9.5″ monochrome LCD *1
8.4″ color LCD *1
10.4″ color LCD
Control unit option slots (depth)
Without optional slot (60 mm)
2 optional slots (110 mm)
4 optional slots (170 mm)
MDI unit
Separate–type MDI for 7.2″/8.4″ LCD (small)
*1
Separate–type MDI for 7.2″/8.4″ LCD
(standard) *1
Separate–type MDI for 9.5″/10.4″ LCD
(standard, horizontal type) *1
Separate–type MDI for 9.5″/10.4″ LCD
(standard, vertical type)
(MDI for 10.4″ LCD, for the Series 160i/180i)
Separate–type MDI for 10.4″ LCD
(PC key, vertical type) *2
Touch pad (for 10.4″ LCD only)
PMC–RB5
(Basic instruction: 0.085 µs/step)
Maximum ladder steps: 24,000
PMC–RB6
(Basic instruction: 0.085 µs/step)
Maximum ladder steps: 32,000
Step sequence function
PMC–Ri
(Basic instruction: 0.085 µs/step)
Maximum ladder steps: 32,000, complying
with IEC1131–3
PMC C
Up to 2MB (PMC–RB5/RB6 required)
Battery–powered memory expansion
Machine interface (I/O link)
Maximum DI/DO
p
oints: 1024/1024
I/O unit model A
M
ax
i
mum
DI/DO
po
i
n
t
s:
1024/1024
I/O unit model B
Operator’s panel I/O module
Connector panel I/O module
Power magnetics cabinet I/O module
Standard machine operator’s panel (FS0 type)
Manual pulse generator
Pendant type manual pulse generator With axis selection and magnification switches
Codeless manual pulse generator Restricted use in Japan
Connectable servo motor FANUC AC servo motor α series
Connectable servo amp. FANUC control motor amp. α series
Connectable position detector
(for full–closed control)
Pulse coder/optical scale
(2–phase pulse interface)
Linear scale interface with absolute addressing reference
mark
Input power supply
24V DC ±10%
