SERIES 16/18/160/180 i PA Descriptions Page 230

Descriptions
B–63122EN/01
A. RANGE OF COMMAND VALUE
APPENDIX
223
(5)Rotation axis
Increment system
IS-A, IS-B
Least input increment 0.001 deg
Least command increment 0.001 deg
Max. programmable dimension 99999.999 deg
Max. rapid traverse *1 240,000 deg/min
Feedrate range *1 1 to 240,000 deg/min
Incremental feed 0.001, 0.01, 0.1, 1deg/step
Tool compensation 0 to 999.999 mm
Backlash compensation 0 to 0.255 deg
(6)Caxis
Increment system
IS–A IS–B
Least input increment 0.01deg 0.001deg
Least command incre-
ment
0.01deg 0.001deg
Max. programmable di-
mension
999999.99deg 99999.999deg
Max. rapid traverse *1 240,000deg/min 240,000deg/min
Feedrate range *1 1 to 240,000deg/min 1 to 240,000deg/min
Incremental feed 0.01, 0.1, 1, 10deg/step 0.001, 0.01, 0.1, 1deg/
step
Backlash compensa-
tion
0 to 2.55deg 0 to 0.255deg
WARNING
The feedrates in the above tables apply when they are
limited only by NC interpolation. When the NC is integrated
into a system, the feedrates are limited by the servo system
as well.
