1. Fanuc
  2. SERIES 16/18/160/180 i PA

SERIES 16/18/160/180 i PA Descriptions Page 21

Descriptions
B–63122EN/01
2. LIST OF SPECIFICATIONS
GENERAL
11
Setting and display
18i–PA
180i–PA
16i–PA
160i–PA
SpecificationsItem
Periodic maintenance screen *1
Maintenance information screen *1
Software operator’s panel
Software operator’s panel general purpose switch
Multi–language display
English
Japanese(Chinese character)
German/French *1
Italian *1
Spanish *1
Data protection key 4 type
Erase screen display *1
Data input/output
Item Specifications
16i–PA
160i–PA
18i–PA
180i–PA
Reader/puncher interface
Reader/puncher(Ch.1)interface
Reader/puncher(Ch.2)interface
Input/output simultaneous operation
Remote buffer
Data server
External I/O device control *1
DNC1 control Specification of 16i/18i–M *1
DNC2 control Specification of 16i/18i–M *1
Modem card control *1
External tool offset
External message
External machine zero point shift
External data input Including above 3 items
External key input
External program input
External workpiece number search 31
External program number search 1 to 9999
Memory card interface For maintenance
Screen hard copy *1
Power motion manager *1
