11. MISCELLANEOUS FUNCTIONS
B–63122EN/01
NC FUNCTION
68
When an 8–digit number after address M is commanded, a 32–bit binary
code is output. Maximum input digits are specified with parameters for
this code. This function is used for on/off at the machine side. A single
M code can be commanded in one block. The following M codes are
decoded and output:
M00 : Program stop
M01 : Optional stop
M02 : End of program
M30 : End of program and tape rewind
The above M codes can also be output in binary codes.
M98 (sub program call) and M99 (return from sub program) and always
processed in the NC so, signal will not be output.
Some of the following M–code operations are performed within the CNC.
Note, however, that M–code signals are output.
Forming mode and cancel forming mode
Workpiece clamp and unclamp
Nibbling mode and cancel nibbling mode
Punching mode and laser mode
WARNING
These M–code operations must be specified within a single
block.
NOTE
These M–code operations are specified by parameters.
11.1
MISCELLANEOUS
FUNCTIONS
