25. DISPLAYING AND SETTING DATA
B–63122EN/01
NC FUNCTION
178
The periodic maintenance screen shows the current statuses of those
consumables that require periodic replacement (backup battery, LCD
backlight, touch pad, etc). An item whose service life has expired is
indicated by the machine run time or the like.
PERIODICAL MAINTENANCE O0001 N12345
(STATUS)
ITEM NAME REMAIN
01 BATTERY FOR CONTROLLER 0H
@ 02 BATTERY FOR PULSECODER 5000H
03 LCD BACK LIGHT 10000H
@ 04 COOLANT 720H
05
06
07
08
09
10
>_
EDIT **** *** *** 19:27:05
[ ][MAINTE ][ ][ ][(OPRT) ]
A pen input device/touch pad used on the LCD display has the following
features:
(1)The soft keys displayed on the lower section of the 10.4–inch color
LCD/MDI panel (F0 to F9, FR, and FL) are replaced by the soft keys
on the touch pad.
(2)The cursor displayed on the 10.4–inch color LCD is controlled from
the touch pad.
(3)A touch–pad–type software machine operator’s panel, realized by C
Executor, can be used.
(4)A touch–pad–type calculator, realized by C Executor, can be used.
(5)A C Executor application program can be created by using the touch
pad.
The history of the maintenance carried out by FANUC service personnel
and machine tool builder can be recorded via the screen. The screen has
the following features:
Alphabetical characters can be input from MDI. (Half–size kana can
be input only when Japanese display is selected.)
The recording screen can be scrolled, line by line.
Edited maintenance information can be read and punched.
Data can be stored to flash ROM.
Full–size (shift JIS) codes can be displayed. (Input codes are read
only.)
25.18
PERIODIC
MAINTENANCE
SCREEN
25.19
TOUCH PAD
25.20
MAINTENANCE
INFORMATION
SCREEN
