SERIES 16/18/160/180 i PA Descriptions Page 57

Descriptions
6. COORDINATE SYSTEMS
B–63122EN/01
NC FUNCTION
48
Six workpiece coordinate systems can be set. But, when that is still not
enough, or when workpiece origin offset value must be set by tape or
changed, this G10 command is used to change workpiece origin offsets.
When G10 is commanded in absolute command (G90), the commanded
workpiece origin offsets becomes the new workpiece origin offsets, and
when G10 is commanded in incremental command (G91), the currently
set workpiece origin offsets plus the commanded workpiece origin
offsets becomes the new workpiece offsets.
G10 L2 Pp _ ;
Pp : Specify workpiece coordinates to which offsets are changed
p: 1 - 6
: Workpiece origin offset value

IP
6.4
WORKPIECE ORIGIN
OFFSET VALUE
CHANGE
(PROGRAMMABLE
DATA INPUT) (G10)
Format
Previous page
Next page
