FANUC Series16i /18i /21i –MA/TA
Embedded Macro
A-77900E
2000.04.11
# Correction/change/addition
1) Release the password for embedded macro programs in FROM by the
keyword.
2) Change the parameters of the calling G-codes, calling program numbers if
necessary.
3) Change the parameter of edit / reference the embedded macro programs if
necessary.
4) Edit the embedded macro programs.
5) Change the parameter of edit / reference the embedded macro programs.
6) Change the series and edition.
7) Store the embedded macro programs in FROM.
It is not possible to change “password”. Please make new embedded macro file
if necessary to change “password”. In order to change “embedded macro
program number”, it is necessary to delete all programs. Please change the
embedded macro program to unlock state and delete all programs.
# Reproduction
1) Output the programs in area of the tape storage memory to an external
device.
2) Save the embedded macro file "INMC" to the memory card by using Boot
system.
3) Store the “INMC” file, which is saved at 2), in FROM by using Boot system.
4) Start up the CNC while pushing the [DELETE] key. (At this time, the
programs in the tape storage memory area are deleted and the embedded
macro programs in FROM are loaded to DRAM.)
