FANUC Series16i /18i /21i –MA/TA
Embedded Macro
A-77900E
2000.04.11
Massage (Display in the place on present time)
# “PROG-SAV” -- Please stores the embedded macro programs.
This display is blink when the embedded macro programs are edited. It
informs that the contents of edited the embedded macro programs are
deleted if the power supply is turned off / on with current state.
In this case, please store the new embedded macro programs to FROM
by <SAVE> operation or reload the old embedded macro programs
from FROM by <RELOAD> operation.
# “PROG-ERR” -- The embedded macro program information is abnormal.
It informs that the content of the embedded macro program information
and the embedded programs is not matched. When the embedded
macro program is edited (state of “PROG-SAVE”) and the power supply
is turned off / on without storing FROM, this display is blink.
In this case, please reload the embedded macro programs from FROM
by <RELOAD> operation.
# “PROG-PRT” -- The range of the embedded macro program number cannot
be changed.
This display is blink when it is not possible to change within the range of
the embedded macro program number of the embedded macro data.
The number set in the range of the embedded macro program number
of the embedded macro data in FROM is different from the parameter
No. 12011 and 12012, and the program exists in CNC.
In this case, please delete all programs (O-9999 + DELETE) operation,
and do <RELOAD> operation.
