FANUC Series 16i/18i/21i-MA/TA Embedded Macro Function Additional Manual Page 5

Additional Manual
4
Edit
Apprv.
Apprv.Apprv.
Apprv.Desig.
Desig.Desig.
Desig.
Sheet
Title
Draw
No.
/
24
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series16i /18i /21i –MA/TA
Embedded Macro
A-77900E
2000.04.11
Embedded macro program (macro program)
The macro programs made by MTB are stored. When the embedded macro program
is edited, an operator edits the program on DRAM and the edited program is stored
in FROM by the softkey operation. When the embedded macro program is edited, it
is necessary to store the program in FROM because the program on DRAM is
deleted when the power supply is turned on again.
Tape storage memory program (user program)
The CNC programs made by a user (operator). Even if the power supply is turned on
again, the programs are not deleted.
(1) Edit of embedded macro program
The macro programs on DRAM can be edited on the program screen. And
parameter setting can prohibit the edit of the embedded macro program. The edit
operation is the same as the edit of the normal user program. Program input/output
operation is also the same as that of the normal user program. The embedded
macro programs and the user programs are distinguished according to the program
number.
(2) Programs writing from DRAM to FROM and programs reading from FROM to DRAM
The embedded macro programs on DRAM can be written to FROM by the softkey
operation. At the same time, the program administrative information and the
embedded macro parameters are forwarded from SRAM to DRAM, and written from
DRAM to FROM. When the power supply is turned on, reading from FROM to DRAM
is automatically done. At this time, this function is checked whether the program
administrative information of SRAM is correct and the parameters for embedded
macro are rewritten by FROM data. The program reading from FROM to DRAM is
also done by the softkey operation. By this operation, the current DRAM area is
overwritten by the data in FROM area.
(3) Input to FROM and output from FROM
The embedded macro program file stored in FROM can be input and output by
BOOT SYSTEM with a memory card.
Previous page
Next page

Contents Summary of FANUC Series 16i/18i/21i-MA/TA Embedded Macro Function Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) TMN00/0064E Date: Apr. 13, 2000 General Manager of Software Laboratory FANUC Series 16i/18i/21i–MA/TA Embedded Macro Function 1. Communicate this report to: Your information • GE Fanuc-N, GE Fanuc-E FANUC Robotics CINCINNATI MILACRON • Machine tool builder Sales agency End
  • Page 2FANUC Series 16i/ 18i/ 21i –MA/TA Specification Embedded Macro Contents 1. Outline ..............................................................................................................................2 2. Specification ........................................................................
  • Page 31. Outline In this function, the macro programs, which are made by the machine tool builder (MTB), are stored in flash ROM. The macro programs, which are stored in flash ROM, are loaded to the program memory area for the embedded macro (DRAM) when the power supply is turned on. And an operator can c
  • Page 42. Specification # Composition of function CNC FROM DRAM SRAM Parameter Parameter Parameter Program Program Program administrative administrative administrative information (2) information information Embedded macro Embedded (4) Tape storage program macro program memory program (3) Distinction accor
  • Page 5Embedded macro program (macro program) The macro programs made by MTB are stored. When the embedded macro program is edited, an operator edits the program on DRAM and the edited program is stored in FROM by the softkey operation. When the embedded macro program is edited, it is necessary to store th
  • Page 6(4) Call of embedded macro It is possible to call the embedded macro programs by using G-code call for the embedded macro. And it is also possible to call them by custom macro call (G65, G66) and subprogram call (M98). Title FANUC Series16i /18i /21i –MA/TA Embedded Macro Draw No. A-77900E Edit Date
  • Page 73. Detail 1) Program number As for the embedded macro program number, the first program number is set to parameter No.12011 and the last program number is set to No.12012. The remainder program numbers become the user program numbers of the tape storage memory area. When the keyword is matched the p
  • Page 82) Edit of embedded macro program The embedded macro programs on DRAM can be edited by the operation same as the CNC programs of the tape storage memory area. And it is possible to input/output by the reader puncher interface. The edit of the embedded macro programs can be prohibited as follows by p
  • Page 9When the parameters are set like above, G-codes of G100-G109 correspond to O8000-O8009 G-codes of G150-G249 correspond to O7500-O7599 G-codes of G900-G929 correspond to O8300-O8399 Such a relation can be set up to ten sets. And it is possible to call the embedded macro programs by using macro call (
  • Page 10At meeting all the following requirements, the parameter number 12013 keyword cannot be changed. (1) There is a password. (Password ≠0) (2) The range of the embedded macro program number in the embedded data of FROM is different from the range of the embedded macro program number in the parameters.
  • Page 11It is also possible to load the macro program in FROM to DRAM by following operation. (1) Select the EDIT mode and display the program screen (2) Push the softkey [PROG]. (3) Push the softkey . (4) Push the right side softkey several times. (5) Push the softkey . (6) Push the softkey <
  • Page 129) Series / Edition The embedded macro file can manage by the series and edition. It is possible to set the four digits number to the parameter No.12015 as the series and the four digits number to the parameter No. 12016 as the edition. And this series / edition can be stored by the operation
  • Page 134. Operation Embedded macro program making procedure # New making (1) 1) Do the program all clear operation. ("O-9999"+[DELETE]) 2) Decide the embedded macro programs Nos. and input the decided programs Nos. to the parameter No.12011 and 12012. 3) Enable to edit the embedded macro programs. (Paramet
  • Page 14# Correction/change/addition 1) Release the password for embedded macro programs in FROM by the keyword. 2) Change the parameters of the calling G-codes, calling program numbers if necessary. 3) Change the parameter of edit / reference the embedded macro programs if necessary. 4) Edit the embedded m
  • Page 15Massage (Display in the place on present time) # “PROG-SAV” -- Please stores the embedded macro programs. This display is blink when the embedded macro programs are edited. It informs that the contents of edited the embedded macro programs are deleted if the power supply is turned off / on with curr
  • Page 165. Notes 1) Please store the embedded macro programs in FROM by the embedded macro program save operation after doing program registration, change and deletion. When the programs store is not executed after changing embedded macro programs, the blinking PROG-SAV is displayed on current time display
  • Page 17all programs. And please change the parameter No.12011 and 12012 afterwards, and change the program number for embedded macro. 4) The password for the embedded macro can not be changed when setting the password once. In order to change the password, please make the file for embedded macro newly. In
  • Page 18and background graphic display system (M series). Title FANUC Series16i /18i /21i –MA/TA Embedded Macro Draw No. A-77900E Edit Date Design Description Sheet 17 /24 Date 2000.04.11 Desig. Apprv.
  • Page 196. Parameters #7 #6 #5 #4 #3 #2 #1 #0 12001 IMREP [ Data type ] Bit IMREP Action in response to an attempt to register an embedded macro program whose number is the same as that of an existing program 0: An alarm is generated. 1: The existing program is deleted, then the new program is registered. N
  • Page 20Number 12010 Valid / invalid to edit and refer for embedded macro program [ Data type ] Byte [ Valid data range ] 0 to 2 By setting the table below, it is possible to enable/disable the embedded macro program to edit and refer. Prm.No.12010 Editing Reference 0 X X 1 X O 2 O O (Note 1) When the CNC p
  • Page 21Number 12011 First program number for embedded macro [ Data type ] 2-Word [ Valid data range ] 1 to 99999999 Number 12012 Last program number for embedded macro [ Data type ] 2-Word [ Valid data range ] 1 to 99999999 The program numbers for embedded macro are set by these parameters. The program num
  • Page 22Number 12013 Password / Keyword for embedded macro [ Data type ] 2-Word [ Valid data range ] -99999999 to 99999999 When the embedded macro programs are stored in FROM, this parameter is set as a password. When store in FROM ends, this parameter becomes 0 automatically. After that, this parameter use
  • Page 23Number 12015 Series for embedded macro [ Data type ] Word [ Valid data range ] 0 to 9999 Number 12016 Edition for embedded macro [ Data type ] Word [ Valid data range ] 0 to 9999 The series and edition of the FROM file for the embedded macro is set. When the embedded macro data is stored, The series
  • Page 24Number st 12020 G-code No. for embedded macro (the 1 set) nd 12023 G-code No. for embedded macro (the 2 set) | | th 12047 G-code No. for embedded macro (the 10 set) [ Data type ] Word [ Valid data range ] 1 to 999 Number st 12021 Macro programs No. for embedded macro (the 1 set) nd 12024 Macro progr
  • Page 25G-code macro for embedded macro is set. These sets can be specified up to ten sets. The priority is given from a small parameter number set when G-code number comes in succession. When either of G-code number, program number or macro program number parameter is set to 0, the set is invalid. The 1st
