F. MEMORY CARD INTERFACE
511
1. Overview
Memory card–based data input/output in the current Series CNC can
be done only with a flash memory card. For those models shipped
from FANUC in and after October 1998, however, a flash ATA card
(5 V version) can also be used for data input/output. Because the flash
ATA card incorporates a storage device and controller, it enables data
input/output for a personal computer equipped with a PCMCIA
interface without using any special PC card writer.
2. Supported hardware versions and software editions
On models other than the FS20i, the following conditions must be
satisfied.
2–1 Hardware
The motherboard must be OF one of the versions listed below.
Model Printed–circuit board
specification
General version
FS16i A20B–8100–0130 12E and later
FS18i A20B–8100–0135 12E and later
FS21i (with SA5) A20B–8100–0136 10E and later
FS21i (with SA1) A20B–8100–0137 10E and later
2–2 Software
The software must be OF one of the editions listed below.
System software
Series/model Edition
B1F1/FS16i–TA Edition 16 or later
B0F1/FS16i–MA Edition 17 or later
BEF1/FS18i–TA Edition 16 or later
BDF1/FS18i–MA Edition 17 or later
DEF1/FS21i–TA Edition 11 or later
DDF1/FS21i–MA Edition 11 or later
Boot software
Series Edition
60M3 Edition 09 or later
ATA CARD
