B-61813E/03 CONNECTIONS 9. TEMPERATURE INPUT MODULE
−101−
9.3 PMC INTERFACE
9.3.1 PMC I/O area
This temperature module uses an input/output area consisting of four
bytes for input and the same number of bytes for output. Each byte of
the input/output area has the following meanings. The terms "input"
and "output" are used in reference to the PMC. When input/output
addresses are assigned to the module, "/4" is used as the module name.
1) Output (PMC → temperature module)
Addresses in the module
0 DO07 to DO00 Period for 4-channel automatic measurement
mode (lower 8 bits)
+1 DO15 to DO08 Period for 4-channel automatic measurement
mode (higher 8 bits)
+2 DO23 to DO16 Module setting data and timing data
+3 DO31 to DO24 Module setting data and timing data
2) Input (temperature module → PMC)
Addresses in the module
0 DI07 to DI00 CH1 temperature data, CH3 temperature data, or
abnormality data (lower 8 bits)
+1 DI12 to DI08 CH1 temperature data, CH3 temperature data, or
abnormality data (higher 5 bits)
DI15 to DI13 Status signal
+2 DI23 to DI16 CH2 temperature data, CH4 temperature data, or
abnormality data (lower 8 bits)
+3 DI28 to DI24 CH2 temperature data, CH4 temperature data, or
abnormality data (higher 5 bits)
DI31 to DI29 Status signal
NOTE
If you are using the PMC-N, NA, or QA (the PMC for
Series 15 or F-D Mate), all addresses up to those
listed above can be used without modifying them if
the data is manipulated in byte (8-bit) units. When
manipulating data in word (16-bit) units, note that the
byte addresses are transposed as shown below.
