FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 175

Connection And Maintenance Manual
1. OUTLINE
We added I/O Unit-MODEL A which is applied to UL/C-UL certificate.
2. ADITIONAL MATTER
We add following item as 2.1 in part I. CONNECTION.
2.1 I/O Unit-A which is applied to UL/C-UL certificate
Difference between units which is applied to UL/C-UL certificate and not applied to UL/C-
UL certificate.
I/O Unit-A which is not applied to
UL/C-UL certificate
I/O Unit-A which is applied to
UL/C-UL certificate
Order number A03B-0807-Jxxx A03B-0819-Jxxx
Specification
(Interface, external
dimension, weight
Same specification
Plastic case Flammability: 94HB Flammability:94V-0
(hard to flame)
Unit label without UL marking UL marking is on the unit label of
base unit and interface module.
- See 1.4 LIST OF UNITS of II.MAINTENANCE for order number of individual units.
- It is possible to use mix of I/O Units which is applied/not applied to UL/C-UL certificate.
We add following underlined item as 3.1 in part I.CONNECTION.
3.1 ENVIRONMENTAL CONDITIONS
Install the cabinet containing the I/O Unit-A where the following conditions are satisfied.
(1) Surrounding temperature
During operation: 0 to 45 °C
0 to 55 °C (Surrounding temperature of I/O Unit-A in the cabinet)
During preservation and transportation: -20 to 60 °C
EDIT
.
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
2/3
DESCRIPTIONDESIG.DATE
FANUC I/O Unit-MODEL A
Additional matter of CONNECTION
MAINTENANCE MANUAL
B-61813E/03-2
