B-61813E/03 MAINTENANCE 3. FUSES
−149−
3 FUSES
The modules listed below have built-in fuses. If a fuse blows, remove
the cause, then replace the fuse with a spare.
Module Indication Rating Fuse specification
Interface module AIF01A PWR is off 3.2A A60L-0001-0290#LM32
Interface module AIF01B PWR is off. 3.2A A60L-0001-0290#LM32
Interface module AIF02C PWR is off. 3.2A A60L-0001-0290#LM32
Output module with 8 DC points AOD08C F is on. 5A A60L-0001-0260#5R00
Output module with 8 DC points AOD08D F is on. 5A A60L-0001-0260#5R00
Output module with 5 AC points AOA05E F is on. 3.15A A60L-0001-0276#3.15
Output module with 8 AC points AOA08E F is on. 3.15A A60L-0001-0276#3.15
Output module with 12 AC points AOA12F F is on. 3.15A A60L-0001-0276#3.15
The fuses are on the PC boards in the modules.
