FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 92

Connection And Maintenance Manual
B-61813E/03 CONNECTIONS 8. HIGH SPEED COUNTER MODULE
−83−
TRA : Transfer A
NOTE
2 Details of STTS
76543210
TRB ALM CSP ME MH OUT2 OUT1 OUT0
OUT0 : Bit 0 of comparison output
OUT1 : Bit 1 of comparison output
OUT2 : Bit 2 of comparison output
MH : Marker hold
ME : Marker enable
CSP : Count stop
ALM : Alarm (disconnection or watch dog alarm)
TRB : Transfer B
NOTE
3 Detail of OUTD
76543210
OUT7 OUT6 OUT5 OUT4 OUT3 OUT2 OUT1 OUT0
OUT0 : Bit 0 of comparison output
OUT1 : Bit 1 of comparison output
OUT2 : Bit 2 of comparison output
OUT3 : Bit 3 of comparison output
OUT4 : Bit 4 of comparison output
OUT5 : Bit 5 of comparison output
OUT6 : Bit 6 of comparison output
OUT7 : Bit 7 of comparison output
NOTE
4 Detail of MODD
76543210
MOD0
MOD0 : Set to 1 after the mode changes to B.
8.3.3 Details of PMC interface signals
(1) PMC inputs (inputs from PMC)
1) TRA and TRB
The counter data is valid when TRA is equal to TRB and
invalid when TRA is not equal to TRB.
