FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 91

Connection And Maintenance Manual
8. HIGH SPEED COUNTER MODULE CONNECTIONS B-61813E/03
−82−
1) Control outputs
CTRL
76543210
MS CE PRS SELECT
PRS : Preset
CE : Count enable
MS : Marker synchronization
2) Details of DTOH, DTOM, and DTOL
The SELECT bits indicate the target data.
SELECT Target data
0 ~ 15 Comparison data 0 to comparison data 15
16 Output data for partition #0 to partition #2 DTOH:#0, M:#1,
L:#2
17 Output data for partition #3 to partition #5 DTOH:#3, M:#4,
L:#5
18 Output data for partition #6 to partition #8 DTOH:#6, M:#7,
L:#8
19 Output data for partition #9 to partition #11 DTOH:#9, M:#10,
L:#11
20 Output data for partition #12 to partition #14 DTOH:#12, M:#13,
L:#14
21 Output data for partition #15 and partition #16 DTOH:#15,
M:#16
22 Counter preset data
(The numbers of DTOH, DTOM, and DTOL indicate the output data
for the partitions specified by the numbers.)
3) PMC inputs (inputs to PMC)
The inputs to the PMC include the status and counter data.
The data is shown below.
0 CNTS (counter H and status)
+1 CNTM (middle 8 bits of counter)
+2 CNTL (lower 8 bits of counter)
+3 STTS (status)
+4 OUTD
+5 MODD
+6 Not used
+7 Not used
NOTE
1 Detail of CNTS
76543210
TRA
Counter H
(
most si
g
nificant 7 bits
)
