FANUC Series 16i/18i/21i-TA/TB Additional Manual Page 12

Additional Manual
A-76286E
Sheet
Title
Draw
No.
16 Apr.19.'04 Addition or Modification of 16)
15 Jul.02.'02 Y.Takeuchi Improvement of status display T.Endo
14 Jun.21.'02 Y.Takeuchi Improvement of status display T.Endo
13 May.27.'02 Y.Takeuchi Addition of status display and improvement of S/T code output T.Endo
12 Mar.18.'02 Y.Takeuchi Availability of direction change movement in auxiliary function T.Endo
11 Jan.22.'02 Y.Takeuchi Availability of Angular axis control and Advanced preview control T.Endo
10 Oct.03.'01 Y.Takeuchi Addition or Modification of "5. About function improvement" T.Endo
Ed.. Date Design Description
Date May.02.’97 Desig. K.Ishida Apprv. T.Nakazato
FANUC Series 16i/18i/21i-TB/TB
Manual Handle Retrace
Specifications
12/40
HDMPH When other paths become direction change prohibition or reverse
movement prohibition:
0:The executing path does not become direction change prohibition or
reverse movement prohibition
1:The executing path becomes direction change prohibition or reverse
movement prohibition
6410 The movement value by 1 pulse of the manual handle
[Data type] Word type
[Unit of data] %
[Valid data range] 0 - 100
Setting the movement value by 1 pulse of handle to be converted into override.
When a manual handle is turned, the actual movement amount of the machine is as
follows.
[Feedrate command value] × [Number of the handle pulse per a second]
× [Handle magnification] × ([Parameter setting value]/100) × (8/1000)
