FANUC Series 16i/18i/21i-TA/TB Additional Manual Page 37

Additional Manual
A-76286E
Sheet
Title
Draw
No.
16 Apr.19.'04 Addition or Modification of 16)
15 Jul.02.'02 Y.Takeuchi Improvement of status display T.Endo
14 Jun.21.'02 Y.Takeuchi Improvement of status display T.Endo
13 May.27.'02 Y.Takeuchi Addition of status display and improvement of S/T code output T.Endo
12 Mar.18.'02 Y.Takeuchi Availability of direction change movement in auxiliary function T.Endo
11 Jan.22.'02 Y.Takeuchi Availability of Angular axis control and Advanced preview control T.Endo
10 Oct.03.'01 Y.Takeuchi Addition or Modification of "5. About function improvement" T.Endo
Ed.. Date Design Description
Date May.02.’97 Desig. K.Ishida Apprv. T.Nakazato
FANUC Series 16i/18i/21i-TB/TB
Manual Handle Retrace
Specifications
37/40
5.10 About improvement concerning the output of S code and T code at the backward movement
5.10.1 General
In manual handle retrace, when movement command and S-code or T-code is commanded
with the same block, the output timing of the S-code and T-code is different, because the
block where S code and T code are output at the forward movement and the backward
movement is different.
In this improvement, the output timing of S-code and T-code is same at the forward
movement and backward movement.
5.10.2 Specifications
This improvement is enabled, when S-code and T-code output improvement parameter
STO(No.6401#7) is set to "1". After forward movement is executed to N8, the output of
T-code at backward movement is as follows.
Default T shows the state of T code in block N1 at the forward movement. T0 is output as
default T output at the backward movement if it is T0 state.
O1000;
At forward movement
At backward movement
before this improvement
Parameter STO
is set
to "0".
At backward movement
after this improvement
Parameter STO is
set to "1".
N1G98G00X0Z0; Default T output
N2G00X-10.T11; T11 output Default T output
N3G00X100.; T11 output
N4G00X10.Z20.T22; T22 output T11 output T not output
N5G00X30.Z30.;
N6G00X-10.Z-20.; T22 output
N7G00X50.Z40.T33; T33 output T22 output T33 output
N8G04X5.;
M30;
13)
