FANUC Series 16i/18i/21i-TA/TB Additional Manual Page 3

Additional Manual
A-76286E
Sheet
Title
Draw
No.
16 Apr.19.'04 Addition or Modification of 16)
15 Jul.02.'02 Y.Takeuchi Improvement of status display T.Endo
14 Jun.21.'02 Y.Takeuchi Improvement of status display T.Endo
13 May.27.'02 Y.Takeuchi Addition of status display and improvement of S/T code output T.Endo
12 Mar.18.'02 Y.Takeuchi Availability of direction change movement in auxiliary function T.Endo
11 Jan.22.'02 Y.Takeuchi Availability of Angular axis control and Advanced preview control T.Endo
10 Oct.03.'01 Y.Takeuchi Addition or Modification of "5. About function improvement" T.Endo
Ed.. Date Design Description
Date May.02.’97 Desig. K.Ishida Apprv. T.Nakazato
FANUC Series 16i/18i/21i-TB/TB
Manual Handle Retrace
Specifications
3/40
1.3 Backward movement
The "backward movement " is that the program executed forward once is executed
backward by turning a manual handle in the negative direction.
The program can be executed backward only for the block executed forward. And, the
number of blocks for it is about 190 blocks. This block number changes by the content of the
commanded program.
The program is executed backward rapidly when a manual handle is turned to the negative
direction rapidly. And the program is executed backward slowly when a manual handle is
turned to the negative direction slowly. The distance traveled per pulse from manual handle
can switch magnification as well as a usual manual handle feed.
2. Details
2.1 Control by the manual handle
2.1.1 Program execution start
The checking mode signal MMOD<G0067#2> is set to "1" in the memory mode (MEM mode)
in order to change the checking mode. Then, the program execution is begun by turning ST
signal from "1" to "0".
If the manual handle check signal MCHK <G0067#3> is set to "1" at this time, the execution
of the program is controlled by a manual handle. The program is executed synchronizing
with rotation of a manual handle.
When a manual handle check signal MCHK<G0067#3> is set to "0", it is controlled as usual
execution.
Note
1.It is necessary to change to the checking mode in order to execute a program forward
and backward with a manual handle. The checking mode signal must not be turned to "1"
on during execution of program.
2.After the signal is turned to "0" during execution of the program, the program cannot be
executed forward and backward.
16)
1)
1)
1)
1)
1)
