FANUC Series 16i/18i/21i-TA/TB Additional Manual Page 16

Additional Manual
A-76286E
Sheet
Title
Draw
No.
16 Apr.19.'04 Addition or Modification of 16)
15 Jul.02.'02 Y.Takeuchi Improvement of status display T.Endo
14 Jun.21.'02 Y.Takeuchi Improvement of status display T.Endo
13 May.27.'02 Y.Takeuchi Addition of status display and improvement of S/T code output T.Endo
12 Mar.18.'02 Y.Takeuchi Availability of direction change movement in auxiliary function T.Endo
11 Jan.22.'02 Y.Takeuchi Availability of Angular axis control and Advanced preview control T.Endo
10 Oct.03.'01 Y.Takeuchi Addition or Modification of "5. About function improvement" T.Endo
Ed.. Date Design Description
Date May.02.’97 Desig. K.Ishida Apprv. T.Nakazato
FANUC Series 16i/18i/21i-TB/TB
Manual Handle Retrace
Specifications
16/40
[Data type] Word type
[Valid data range] 0 - 9999
The group of M-code at reverse movement is set.
The reverse movement of M-code outputs a modal M-code of the same group set by the
parameter.
The first M-code of each group is the default value. The M-code of each group returns to
default value by reset.
When the number of M-codes of one group is three or less, set "0" in the parameter not
use.
The backward movement of M0 is output M0 regardless of parameter. '0' set in the
parameter is invalid.
The M-code, which is not set by this parameter, outputs the same M-code of forward
movement.
It is only the first M-code of each group which can output the M-code of the same group
in reverse movement. When there are two M-codes or more in a block, same M-code as
forward movement is output to the M-code since the second.
Note
The above-mentioned M-code group is default setting. The M-code groups number and the
M-codes number of one-group changes by the parameter HDMC5 and HDMC8(No.6410).
